Army integrates countermeasures, sensor into MAPS framework


March 04, 2019

Mariana Iriarte

Technology Editor

Military Embedded Systems

Lockheed Martin photo

ORLANDO, Fla. The U.S. Army completed the integration of three countermeasures and a cueing sensor into the Modular Active Protection Systems (MAPS) framework with the support from Lockheed Martin and its industry partners. The integration was completed during a six-week "rodeo" conducted at Redstone Arsenal, Alabama.

In a series of live-fire tests, the MAPS-enabled systems defeated 15 out of 15 anti-tank guided missiles by jamming their signals, causing them to fly off-target.

Lockheed Martin engineers led hardware and software integration of an Ariel Photonics countermeasure into the MAPS framework ahead of the tests. They also supported U.S. Army Combat Capabilities Development Command Ground Vehicle Systems Center efforts with BAE Systems and Northrop Grumman in integrating two other countermeasures and a cueing sensor.

Lockheed Martin was awarded the initial MAPS prototype controller contract in 2014 and continues to manufacture and deliver base kits to MAPS stakeholders. The base kit consists of a controller, user interface, power management distribution system, network switch and application software. It provides processing power to MAPS-enabled sensors and countermeasures and directs them in defeating incoming missiles and rockets.

The base kit supports the rapid integration of MAPS framework-compliant sensors and countermeasures to detect and defeat threats targeting MAPS-equipped vehicles. It is designed to protect current combat vehicles, as well as support future vehicle protection system capabilities.
