Sensor Interface Unit - SIU33
Eletter Product
Configure to Customize
NAI's SIU33 is a highly configurable rugged system or subsystem. It is ideally suited for rugged military, industrial, and commercial applications that require high-density I/O, communications, Ethernet switching, and processing. The SIU33 uses up to three NAI field-proven 3U cPCI boards to deliver off-the-shelf solutions that accelerate deployment of SWaP-optimized systems – with little or no NRE.
Architected for Versatility
Built on NAI's Custom-On-Standard Architecture™ (COSA™), the SIU33 offers a choice of more than 40 intelligent I/O, communications, and Ethernet switch functions, as well as Single Board Computer (SBC) options. Pre-existing, fully-tested functions can be quickly and easily combined in an unlimited number of ways to meet system requirements. Individually dedicated I/O and communication processors allow mission computers to manage, monitor, and control the functions via single or dual Ethernet ports. Alternately, select one of NAI's 3U cPCI SBC options.
All products are designed to operate under extreme temperature, shock, vibration, and EMI environments. EMI filters and gaskets meet or exceed MIL-STD-461F and MIL-STD-810G requirements.
Software Support Kit (SSK)
If required, the SIU33 offers a choice of 3U cPCI processors: Freescale PowerPC QorIQ® P2041, Intel® Core™ i7, Intel® Atom™, and ARM Cortex-A9, enabling customers to choose their ideal SBC. Each SBC supports NAI's COSA™ architecture to maximize configurability, versatility, and field-proven reliability. Software support includes Wind River® Linux and VxWorks®, Xilinx® PetaLinux, and Windows® Embedded Standard 7. All I/O and communication libraries are available.
Eliminate man-months of integration with a configured, field-proven system from NAI.
Features
- 3 x 3U cPCI Slots – allows installation of up to nine I/O and communications modules
- 40+ modules to choose from
- SBC-less stand-alone operation supported via Ethernet connection to your mission computer
- Processor options: Freescale PowerPC QorIQ® P2041, Intel® Core™ i7, Intel® Atom™ or ARM Cortex-A9
- MIL-STD-461F, MIL-STD-1275 & 704A
- Customer configurable I/O, communications and processing
- Fast boot capability
- Reduced SWaP
- COTS/NDI
- Sense & response system
- Wind River® Linux / VxWorks®, Altera Linux, Windows® Embedded Standard 7 OS Support
- VICTORY interface services (Contact factory)
- Continuous Background Built in Test (BIT)
- Operating temp: -40°C to +71°C conduction cooled
- 28 VDC input
| North Atlantic Industries | 631-567-1100 | Contact: www.naii.com |
