Pentek Accelerates Real-Time Recording with New Talon Recorder for Quartz RFSoC

UPPER SADDLE RIVER, NJ – Pentek, Inc. today introduced a new addition to the Talon® Series of recorders, the Model RTR 2757 4U 19-inch rackmount recorder.

This new recorder complements Pentek's Quartz RFSoC products that stream digitized wide bandwidth signals across 100 Gigabit Ethernet. The RTR 2757 is capable of capturing these streams in real time at rates as high as 12.5 Gigabytes per second.

“The Quartz RFSoC has gained tremendous popularity with our customers. However, its multi-channel wideband A/D converters produce data at a rate that pushes the limits of data recorders,” stated Chris Tojeira, product director of Pentek's Recording Systems. “We leveraged the performance enhancements of today's storage technology and updated our design architecture to handle these challenging requirements,” he continued.

The RTR 2757 was designed with performance and rugged environments in mind. It includes up to 122 TB of NVMe (Non-Volatile Memory Express) storage, using high-performance NVME U.2 drives in a RAID0 configuration to provide extremely high-speed real-time recording. Drives are front-panel removable via eight individual drive trays. The independent operating system drive is also removable via the front panel. This architecture improves the recording speed by fifty percent over previous generations of Talon recorders.

The industrial grade 4U rackmount chassis of the RTR 2757 houses a dual Xeon server class motherboard. It is optimized for cooling and ruggedized to operate in challenging environments. A single QSFP28 optical port supports up to four independent UDP streams for a combined real-time recording rate up to 12.5 GB/s (100 Gigabits/s).

This allows users to stream data from four of the RFSoC's A/D channels over 100 Gigabit Ethernet and capture them as independent files on the recorder. The recorder captures only the Ethernet payload, providing data files similar to other Talon recorders and compatibility with the SystemFlow signal analysis tools.

Ease of Operation
All Talon recorders are built on a Microsoft Windows platform and include Pentek’s SystemFlow software, featuring a GUI (graphical user interface), the Signal Viewer and API (Application Programming Interface). The GUI provides intuitive controls for out-of-the-box turn-key operation using point-and-click configuration management.

Configurations are easily stored and recalled for single-click setup. The Signal Viewer provides a virtual oscilloscope and spectrum analyzer to monitor signals before, during and after data collection. The C-callable API allows users to integrate the recorder control into larger application systems. Enhancements to the GUI allow more efficient configuration of the recording channels.

The data format used for storage follows the NTFS standard, allowing users to remove drives from the instrument and read the data using standard Windows-based systems, eliminating the need for file format conversion.

Free Demo
Pentek provides a Talon Recording System Simulator for evaluation of the SystemFlow software package. This free trial package is available for download at: http://www.pentek.com/systemflow/systemflow.cfm#SystemFlowSimulator.

Talon Family Summary

  • RTV Value Series: Low-cost rackmount systems for laboratory environments
  • RTS Commercial Series: Rackmount systems for laboratory environments
  • RTR Portable Series: Rugged portable systems for field use
  • RTR Rackmount Series: Rugged rackmount systems for field use
  • RTX Extreme Series: Rugged rackmount systems for extreme environments

Pricing and Availability
For the latest pricing and availability information, please contact John Eklund by phone at (201) 818-5900, or by email at [email protected]

About Pentek
Pentek, an ISO 9001:2015 certified company, designs and manufactures innovative commercial and rugged DSP boards and real-time system recorders for commercial, government and military systems including radar, communications, SIGINT, defense, medical and industrial control applications. Pentek offers powerful VPX, FMC, FMC+, AMC, XMC, cPCI and PCIe board solutions featuring high-performance Xilinx FPGAs. Pentek equips all boards and recorder products with high-performance I/O including gigabit serial interfaces, powerful software development tools and offers strong DSP software support.

###

Pentek, Talon, Quartz, and SystemFlow are trademarks or registered trademarks of Pentek, Inc. Brand or product names are registered trademarks or trademarks of their respective holders.

For access to the release and data sheets, please visit: https://www.pentek.com/whatsnew/viewrelease.cfm?index=256 For Pentek’s North American & International sales contacts please go to https://www.pentek.com/contact/contact.cfm?HID2=TMReps#Reps
