Acromag Releases the Smallest Mezzanine Module with the Power of a Zynq UltraScale+ MPSoC for I/O Processing and Programmable Logic

Press Release

December 03, 2020

Acromag Releases the Smallest Mezzanine Module with the Power of a Zynq UltraScale+ MPSoC for I/O Processing and Programmable Logic
Acromag image.

Wixom, MI: Acromag’s new APZU series expands their offering of mini PCIe-based AcroPack modules with a programmable I/O solution featuring the Xilinx Zynq UltraScale+ multiprocessor system-on-a-chip (MPSoC). Three models are available offering a choice of digital I/O interfaces with 28 TTL, 20 TTL and 3 RS422/485, or 14 LVDS signals. These mezzanine modules mount on a variety of AcroPack carrier cards for PCIe, VPX, and other platforms allowing developers to mix and match I/O combinations on a single board for embedded applications running on Linux, Windows, or VxWorks operating systems.

The APZU’s Zynq 3CG MPSoC combines a feature-rich ARM-based processing system and programmable logic in a single device. Two dual-core ARM Cortex CPUs (A53 application processor and R5 real-time processor) deliver high-performance computation capability. 154k logic cells provide plenty of FPGA processing blocks for hardware acceleration and compute-intensive tasks. Additional resources include large on-chip memory, external memory interfaces, and a rich set of peripheral connectivity interfaces. Gigabit Ethernet, USB 2.0, and USB-UART interfaces are supported.

AcroPack modules are only 30mm x 70mm. They use a standard mini PCIe edge connector but add a down-facing 100-pin connector which internally routes I/O signals through the carrier card to secure field connectors, thus eliminating loose cables and increasing reliability. More information about the AcroPack series is available from Acromag’s website at www.Acromag.com/AcroPacks.

“Designers can increase overall system performance by leveraging the tightly-coupled CPU and FPGA computing engines for different signal processing tasks in a very small and cost-effective form factor.” stated Robert Greenfield, Acromag’s Business Development Manager.

Designed for defense and aerospace systems, these AcroPacks are ideal for adaptive filtering, protocol conversion, simulation, HIL test, motor control, image processing, and sensor fusion applications. The COTS modules can be used in PCIe servers, VPX or CompactPCI Serial chassis, and small form factor embedded computers.

About Acromag:
Founded in 1957, Acromag, Inc. designs and manufactures hi-tech electronics. They are an international corporation headquartered near Detroit, Michigan with a global network of sales representatives and distributors. Acromag offers a complete line of embedded computing and I/O solutions including general purpose I/O boards, single-board computers, FPGA modules, embedded computers, COM Express products, mezzanine modules, wiring accessories, and software. Industries served include military, aerospace, manufacturing, transportation, utilities, and scientific research laboratories.

For more information about Acromag products, call Inside Sales at (248) 295-0310 or Marketing Communications at (248) 295-0866. The web site is www.acromag.com.
